NVIDIA Quadro 4000M vs NVIDIA GeForce 940MX

Compare NVIDIA Quadro 4000M 2 GB vs NVIDIA GeForce 940MX, specs and GPU benchmark score. Which is the better graphics card for the money?

Benchmark Score
Other Benchmarks
Specifications
Comments (0)
Popular Comparisons

GPU Comparison

Quickly search and compare graphics cards

Benchmark Score

Overall Score

General gaming and workstation score

250 points

306 points

22% slightly better overall score

Flux Core frame rate

Volumetric ray casting test, a computationally expensive method of rendering high-quality scenes

7 FPS

8 FPS

1 FPS slightly higher Flux Core frame rate

Electron frame rate

Randomly generated noise sphere test

4 FPS

6 FPS

2 FPS significantly higher Electron frame rate

City frame rate

Procedurally generated city scene with voxel rendering

4 FPS

5 FPS

1 FPS significantly higher City frame rate

Clouds frame rate

Real-time noise calculation and ray marching test

3 FPS

5 FPS

2 FPS significantly higher Clouds frame rate

Free GPU Benchmark

Want to compare your graphics card against the Quadro 4000M and the GeForce 940MX? Download our free and quick PC Performance Test.

Download GPU Benchmark

Other Benchmarks

Geekbench 5 (OpenCL) score

OpenCL compute benchmark

4216 points

6582 points

56% significantly higher Geekbench 5 (OpenCL) score

Geekbench 6 (OpenCL) score

OpenCL compute benchmark

5211 points

6410 points

23% slightly higher Geekbench 6 (OpenCL) score

Specifications

Core Clock Speed

Nominal chip frequency

475 MHz

1004 MHz

111% significantly higher core clock speed

Memory Bus Width

Number of parallel lines to the memory chips

256 Bit

300% significantly larger memory bus width

64 Bit

Memory Bandwidth

Data transfer speed between GPU core and memory

80 GB/s

399% significantly higher memory bandwidth

16.02 GB/s

TDP

Thermal Design Power: Measure of heat generated by the GPU

100 W

23 W

334% significantly lower TDP

Pixel Rate

Number of pixels that can be rendered per second

6.65 Gigapixels/s

9.94 Gigapixels/s

49% significantly higher pixel rate

Texture Rate

Number of textured pixels that can be rendered per second

26.6 Gigatexels/s

29.81 Gigatexels/s

12% slightly higher texture rate

Shading Units

Number of processors dedicated to shader processing

336

384

14% slightly more shading units

Texture Mapping Units

Number of processors dedicated to applying textures

133% significantly more texture mapping units

Render Output Processors

Number of processors dedicated to final pixel rendering

300% significantly more render output processors

Other details

Rank

Ranking in the hardwareDB database

399th of 586

376th of 586

Release date

The official date of release of this chip

2016 June

Memory Type

The type of memory used by this chip

GDDR5

DDR3

DirectX Support

Maximum version of DirectX supported

11.0

12.0

OpenGL Support

Maximum version of OpenGL supported

4.5

4.6

Quadro 4000M vs GeForce 940MX benchmarks

In our benchmarks, the Quadro 4000M beats the GeForce 940MX in gaming performance.

In our comparison, the GeForce 940MX has a significantly higher core clock speed. The core clock speed (or base speed) is the frequency at which the GPU core runs. This metric makes sense when comparing GPUs of a similar architecture or generation.

In addition, the GeForce 940MX has a significantly lower TDP at 23 W when compared to the Quadro 4000M at 100 W. Heat output doesn't match power consumption directly but, it's a good estimate.

According to the results of the hardwareDB benchmark utility, the Quadro 4000M is faster than the GeForce 940MX.
