NVIDIA GeForce GTX 660 Ti vs NVIDIA GeForce GTX 1060 5GB

Compare NVIDIA GeForce GTX 660 Ti 3 GB vs NVIDIA GeForce GTX 1060 5GB, specs and GPU benchmark score. Which is the better graphics card for the money?

Benchmark Score
Other Benchmarks
Specifications
Comments (0)
Popular Comparisons

GPU Comparison

Quickly search and compare graphics cards

Benchmark Score

Overall Score

General gaming and workstation score

1159 points

2438 points

110% significantly better overall score

Flux Core frame rate

Volumetric ray casting test, a computationally expensive method of rendering high-quality scenes

27 FPS

49 FPS

22 FPS significantly higher Flux Core frame rate

Electron frame rate

Randomly generated noise sphere test

16 FPS

39 FPS

23 FPS significantly higher Electron frame rate

City frame rate

Procedurally generated city scene with voxel rendering

18 FPS

31 FPS

13 FPS significantly higher City frame rate

Clouds frame rate

Real-time noise calculation and ray marching test

13 FPS

32 FPS

20 FPS significantly higher Clouds frame rate

Free GPU Benchmark

Want to compare your graphics card against the GeForce GTX 660 Ti and the GeForce GTX 1060 5GB? Download our free and quick PC Performance Test.

Download GPU Benchmark

Other Benchmarks

Blender score

Cycles Render (Samples per minute)

150.80 points

324.97 points

115% significantly higher Blender score

Geekbench 5 (CUDA) score

CUDA compute benchmark

11298 points

30206 points

167% significantly higher Geekbench 5 (CUDA) score

Geekbench 5 (OpenCL) score

OpenCL compute benchmark

14647 points

33671 points

129% significantly higher Geekbench 5 (OpenCL) score

Geekbench 5 (Vulkan) score

Vulkan compute benchmark

14555 points

36656 points

151% significantly higher Geekbench 5 (Vulkan) score

Geekbench 6 (OpenCL) score

OpenCL compute benchmark

15295 points

35111 points

129% significantly higher Geekbench 6 (OpenCL) score

Geekbench 6 (Vulkan) score

Vulkan compute benchmark

16140 points

33988 points

110% significantly higher Geekbench 6 (Vulkan) score

Specifications

Core Clock Speed

Nominal chip frequency

915 MHz

1506 MHz

64% significantly higher core clock speed

Boost Clock Speed

Higher turbo frequency when power conditions are met

980 MHz

1709 MHz

74% significantly higher boost clock speed

Memory Bus Width

Number of parallel lines to the memory chips

192 Bit

20% slightly larger memory bus width

160 Bit

Memory Bandwidth

Data transfer speed between GPU core and memory

144.2 GB/s

160.2 GB/s

11% slightly higher memory bandwidth

TDP

Thermal Design Power: Measure of heat generated by the GPU

150 W

120 W

25% slightly lower TDP

Pixel Rate

Number of pixels that can be rendered per second

27.44 Gigapixels/s

68.36 Gigapixels/s

149% significantly higher pixel rate

Texture Rate

Number of textured pixels that can be rendered per second

109.8 Gigatexels/s

136.7 Gigatexels/s

24% slightly higher texture rate

Floating Point Performance

Raw number of floating point operations per second

2.63 TFLOPS

4.38 TFLOPS

66% significantly better floating point performance

Shading Units

Number of processors dedicated to shader processing

1344

5% slightly more shading units

1280

Texture Mapping Units

Number of processors dedicated to applying textures

112

40% slightly more texture mapping units

Render Output Processors

Number of processors dedicated to final pixel rendering

66% significantly more render output processors

Other details

Rank

Ranking in the hardwareDB database

253rd of 586

181st of 586

Release date

The official date of release of this chip

2017 December

Memory Type

The type of memory used by this chip

GDDR5

DirectX Support

Maximum version of DirectX supported

11.0

12.0

OpenGL Support

Maximum version of OpenGL supported

4.5

4.6

GeForce GTX 660 Ti vs GeForce GTX 1060 5GB benchmarks

According to the hardwareDB Benchmark, the GeForce GTX 1060 5GB GPU is faster than the GeForce GTX 660 Ti in gaming.

The GeForce GTX 1060 5GB has a significantly higher core clock speed. This is the frequency at which the graphics core is running at. While not necessarily an indicator of overall performance, this metric can be useful when comparing two GPUs based on the same architecture. In addition, the GeForce GTX 1060 5GB also has a significantly higher boost clock speed. This is a frequency that can be reached if the GPU is cooled sufficiently and has enough power.

In addition, the GeForce GTX 1060 5GB has a slightly lower TDP at 120 W when compared to the GeForce GTX 660 Ti at 150 W. This is not a measure of performance, but rather the amount of heat generated by the chip when running at its highest speed.

In terms of raw gaming performance in our GPU benchmark, the GeForce GTX 1060 5GB is better than the GeForce GTX 660 Ti.
