AMD Radeon RX 6800 vs NVIDIA GeForce RTX 5070

Compare AMD Radeon RX 6800 16 GB vs NVIDIA GeForce RTX 5070, specs and GPU benchmark score. Which is the better graphics card for the money?

Benchmark Score
Other Benchmarks
Specifications
Comments (0)
Popular Comparisons

GPU Comparison

Quickly search and compare graphics cards

NVIDIA GeForce RTX 5070

Price

The cheapest price from our partner retailers

$ 519.00

$ 47.99 slightly less expensive

$ 566.99

Benchmark Score

Overall Score

General gaming and workstation score

9578 points

13240 points

38% slightly better overall score

Flux Core frame rate

Volumetric ray casting test, a computationally expensive method of rendering high-quality scenes

196 FPS

310 FPS

114 FPS significantly higher Flux Core frame rate

Electron frame rate

Randomly generated noise sphere test

143 FPS

156 FPS

13 FPS slightly higher Electron frame rate

City frame rate

Procedurally generated city scene with voxel rendering

173 FPS

229 FPS

56 FPS significantly higher City frame rate

Clouds frame rate

Real-time noise calculation and ray marching test

83 FPS

125 FPS

42 FPS significantly higher Clouds frame rate

Free GPU Benchmark

Want to compare your graphics card against the Radeon RX 6800 and the GeForce RTX 5070? Download our free and quick PC Performance Test.

Download GPU Benchmark

Other Benchmarks

3DMark Graphics score

High-end graphics benchmark

16155 points

207% significantly higher 3DMark Graphics score

5256 points

Blender score

Cycles Render (Samples per minute)

1896.07 points

6174.82 points

225% significantly higher Blender score

Geekbench 6 (OpenCL) score

OpenCL compute benchmark

130005 points

188870 points

45% significantly higher Geekbench 6 (OpenCL) score

Geekbench 6 (Vulkan) score

Vulkan compute benchmark

133046 points

181089 points

36% slightly higher Geekbench 6 (Vulkan) score

Specifications

Core Clock Speed

Nominal chip frequency

1815 MHz

2325 MHz

28% slightly higher core clock speed

Boost Clock Speed

Higher turbo frequency when power conditions are met

2105 MHz

2512 MHz

19% slightly higher boost clock speed

Memory Bus Width

Number of parallel lines to the memory chips

256 Bit

33% slightly larger memory bus width

192 Bit

Memory Bandwidth

Data transfer speed between GPU core and memory

512 GB/s

672 GB/s

31% slightly higher memory bandwidth

TDP

Thermal Design Power: Measure of heat generated by the GPU

250 W

Identical

250 W

Pixel Rate

Number of pixels that can be rendered per second

202.1 Gigapixels/s

0.55% slightly higher pixel rate

201 Gigapixels/s

Texture Rate

Number of textured pixels that can be rendered per second

505.2 Gigatexels/s

4% slightly higher texture rate

482.3 Gigatexels/s

Shading Units

Number of processors dedicated to shader processing

3840

6144

60% significantly more shading units

Texture Mapping Units

Number of processors dedicated to applying textures

240

25% slightly more texture mapping units

192

Render Output Processors

Number of processors dedicated to final pixel rendering

20% slightly more render output processors

Other details

Rank

Ranking in the hardwareDB database

41st of 597

27th of 597

Family

The product line

Radeon RX 6000 Series

Release date

The official date of release of this chip

2020 November

2025 March

Memory Type

The type of memory used by this chip

GDDR6

GDDR7

DirectX Support

Maximum version of DirectX supported

12.0

OpenGL Support

Maximum version of OpenGL supported

4.6

Radeon RX 6800 vs GeForce RTX 5070 benchmarks

For gaming, the GeForce RTX 5070 graphics card is better than the Radeon RX 6800 in our tests.

Our database shows that the GeForce RTX 5070 has a slightly higher core clock speed. This is the frequency at which the graphics core is running at. While not necessarily an indicator of overall performance, this metric can be useful when comparing two GPUs based on the same architecture. In addition, the GeForce RTX 5070 also has a slightly higher boost clock speed. This is a frequency that can be reached if the GPU is cooled sufficiently and has enough power.

In addition, both the Radeon RX 6800 and the GeForce RTX 5070 have an identical TDP. Heat output doesn't match power consumption directly but, it's a good estimate.

According to the results of the hardwareDB benchmark utility, the GeForce RTX 5070 is faster than the Radeon RX 6800.
