NVIDIA Quadro P4200 Max-Q vs NVIDIA Quadro RTX 4000

Compare NVIDIA Quadro P4200 Max-Q vs NVIDIA Quadro RTX 4000 8 GB, specs and GPU benchmark score. Which is the better graphics card for the money?

Benchmark Score
Other Benchmarks
Specifications
Comments (0)
Popular Comparisons

GPU Comparison

Quickly search and compare graphics cards

Benchmark Score

Overall Score

General gaming and workstation score

3440 points

4988 points

44% significantly better overall score

Flux Core frame rate

Volumetric ray casting test, a computationally expensive method of rendering high-quality scenes

76 FPS

115 FPS

40 FPS significantly higher Flux Core frame rate

Electron frame rate

Randomly generated noise sphere test

52 FPS

66 FPS

14 FPS slightly higher Electron frame rate

City frame rate

Procedurally generated city scene with voxel rendering

48 FPS

78 FPS

30 FPS significantly higher City frame rate

Clouds frame rate

Real-time noise calculation and ray marching test

44 FPS

50 FPS

6 FPS slightly higher Clouds frame rate

Free GPU Benchmark

Want to compare your graphics card against the Quadro P4200 Max-Q and the Quadro RTX 4000? Download our free and quick PC Performance Test.

Download GPU Benchmark

Other Benchmarks

Blender score

Cycles Render (Samples per minute)

458.13 points

2173.35 points

374% significantly higher Blender score

Geekbench 5 (OpenCL) score

OpenCL compute benchmark

40459 points

85184 points

110% significantly higher Geekbench 5 (OpenCL) score

Geekbench 6 (OpenCL) score

OpenCL compute benchmark

42672 points

84977 points

99% significantly higher Geekbench 6 (OpenCL) score

Specifications

Core Clock Speed

Nominal chip frequency

1215 MHz

20% slightly higher core clock speed

1005 MHz

Boost Clock Speed

Higher turbo frequency when power conditions are met

1480 MHz

1545 MHz

4% slightly higher boost clock speed

Memory Bus Width

Number of parallel lines to the memory chips

256 Bit

Identical

256 Bit

Memory Bandwidth

Data transfer speed between GPU core and memory

224.4 GB/s

416 GB/s

85% significantly higher memory bandwidth

TDP

Thermal Design Power: Measure of heat generated by the GPU

100 W

60% significantly lower TDP

160 W

Pixel Rate

Number of pixels that can be rendered per second

94.72 Gigapixels/s

98.88 Gigapixels/s

4% slightly higher pixel rate

Texture Rate

Number of textured pixels that can be rendered per second

213.1 Gigatexels/s

222.5 Gigatexels/s

4% slightly higher texture rate

Shading Units

Number of processors dedicated to shader processing

2304

Identical

2304

Texture Mapping Units

Number of processors dedicated to applying textures

144

Identical

144

Render Output Processors

Number of processors dedicated to final pixel rendering

Identical

Other details

Rank

Ranking in the hardwareDB database

140th of 597

102nd of 597

Release date

The official date of release of this chip

2018 February

2018 November

Memory Type

The type of memory used by this chip

GDDR5

GDDR6

DirectX Support

Maximum version of DirectX supported

12.0

OpenGL Support

Maximum version of OpenGL supported

4.6

Quadro P4200 Max-Q vs Quadro RTX 4000 comparison

In our benchmarks, the Quadro RTX 4000 beats the Quadro P4200 Max-Q in gaming performance.

In our comparison, the Quadro P4200 Max-Q has a slightly higher core clock speed. This is the frequency at which the graphics core is running at. While not necessarily an indicator of overall performance, this metric can be useful when comparing two GPUs based on the same architecture. Despite this, the Quadro RTX 4000 has a slightly higher boost clock speed. The boost clock speed is the frequency that the GPU core can reach if the temperature is low enough. The allows for higher performance in certain scenarios.

In addition, the Quadro P4200 Max-Q has a significantly lower TDP at 100 W when compared to the Quadro RTX 4000 at 160 W. TDP (Thermal Design Power) measures total heat output from the chip.

In conclusion, all specs and GPU benchmarks considered, will recommend the Quadro RTX 4000 over the Quadro P4200 Max-Q.
