Intel Iris Xe vs NVIDIA GeForce GTX 870M

Compare Intel Iris Xe vs NVIDIA GeForce GTX 870M, specs and GPU benchmark score. Which is the better graphics card for the money?

Benchmark Score
Other Benchmarks
Specifications
Comments (0)
Popular Comparisons

GPU Comparison

Quickly search and compare graphics cards

Benchmark Score

Overall Score

General gaming and workstation score

974 points

Identical

974 points

Flux Core frame rate

Volumetric ray casting test, a computationally expensive method of rendering high-quality scenes

24 FPS

2 FPS slightly higher Flux Core frame rate

22 FPS

Electron frame rate

Randomly generated noise sphere test

14 FPS

0 FPS slightly higher Electron frame rate

14 FPS

City frame rate

Procedurally generated city scene with voxel rendering

15 FPS

Identical

15 FPS

Clouds frame rate

Real-time noise calculation and ray marching test

10 FPS

11 FPS

0 FPS slightly higher Clouds frame rate

Free GPU Benchmark

Want to compare your graphics card against the Iris Xe and the GeForce GTX 870M? Download our free and quick PC Performance Test.

Download GPU Benchmark

Other Benchmarks

Blender score

Cycles Render (Samples per minute)

100.90 points

150.78 points

49% significantly higher Blender score

Geekbench 5 (OpenCL) score

OpenCL compute benchmark

14184 points

28% slightly higher Geekbench 5 (OpenCL) score

11021 points

Geekbench 5 (Vulkan) score

Vulkan compute benchmark

14105 points

25% slightly higher Geekbench 5 (Vulkan) score

11207 points

Geekbench 6 (OpenCL) score

OpenCL compute benchmark

11957 points

12659 points

5% slightly higher Geekbench 6 (OpenCL) score

Specifications

Core Clock Speed

Nominal chip frequency

300 MHz

941 MHz

213% significantly higher core clock speed

Boost Clock Speed

Higher turbo frequency when power conditions are met

1100 MHz

13% slightly higher boost clock speed

967 MHz

TDP

Thermal Design Power: Measure of heat generated by the GPU

15 W

566% significantly lower TDP

100 W

Pixel Rate

Number of pixels that can be rendered per second

13.2 Gigapixels/s

27.08 Gigapixels/s

105% significantly higher pixel rate

Texture Rate

Number of textured pixels that can be rendered per second

26.4 Gigatexels/s

108.3 Gigatexels/s

310% significantly higher texture rate

Floating Point Performance

Raw number of floating point operations per second

8.45 TFLOPS

225% significantly better floating point performance

2.60 TFLOPS

Shading Units

Number of processors dedicated to shader processing

384

1344

250% significantly more shading units

Texture Mapping Units

Number of processors dedicated to applying textures

112

366% significantly more texture mapping units

Render Output Processors

Number of processors dedicated to final pixel rendering

100% significantly more render output processors

Other details

Rank

Ranking in the hardwareDB database

267th of 586

266th of 586

Release date

The official date of release of this chip

2020 September

2014 March

Memory Type

The type of memory used by this chip

DDR4

GDDR5

DirectX Support

Maximum version of DirectX supported

12.0

OpenGL Support

Maximum version of OpenGL supported

4.6

Iris Xe vs GeForce GTX 870M comparison

According to the hardwareDB Benchmark, the GeForce GTX 870M GPU is faster than the Iris Xe in gaming.

In our comparison, the GeForce GTX 870M has a significantly higher core clock speed. This is the frequency at which the graphics core is running at. While not necessarily an indicator of overall performance, this metric can be useful when comparing two GPUs based on the same architecture. Despite this, the Iris Xe has a slightly higher boost clock speed. This is a frequency that can be reached if the GPU is cooled sufficiently and has enough power.

In addition, the Iris Xe has a significantly lower TDP at 15 W when compared to the GeForce GTX 870M at 100 W. Heat output doesn't match power consumption directly but, it's a good estimate.

In terms of raw gaming performance in our GPU benchmark, the GeForce GTX 870M is better than the Iris Xe.
