AMD Radeon RX 6700 XT

AMD Radeon RX 6700 XT Benchmark and Specs

AMD Radeon RX 6700 XT GPU benchmark, specs and release date - 12 GB AMD Radeon RX 6000 Series Graphics card rating. How good is the Radeon RX 6700 XT for gaming?

Benchmark Score

72 %
Very Good score from 26 samples
Low uncertainty
Performance
Very Good
Ranking
24th of 549
Popularity
12th of 549
Samples
26 benchmarks

Quick compare

Search for a CPU to compare against or choose a popular comparison below.

GPU Comparison

The AMD Radeon RX 6700 XT compared against popular alternatives. Compare against more GPUs with our GPU Comparison Tool.

NVIDIA GeForce RTX 3080
109 %
AMD Radeon RX 6750 XT
76 %
NVIDIA GeForce RTX 3070
73 %
AMD Radeon RX 6700 XT
72 %
NVIDIA GeForce RTX 3060 Ti
65 %
AMD Radeon RX 6600 XT
54 %
NVIDIA GeForce RTX 3060
51 %

GPU benchmarks

Here are the performance results of this graphics card in both the hardwareDB Benchmark and other benchmark utilities. Synthetic tests are an estimation of real-world performance using consistent and repeatable benchmarks. All tests were performed at 1920 x 1080 resolution.

Flux Core

Volumetric ray casting test, a computationally expensive method of rendering high-quality scenes

301 FPS average
214 FPS 10% low
203 FPS 1% low

Electron

Randomly generated noise sphere test

225 FPS average
220 FPS 10% low
206 FPS 1% low

City

Procedurally generated city scene with voxel rendering

267 FPS average
221 FPS 10% low
210 FPS 1% low

Clouds

Real-time noise calculation and ray marching test

128 FPS average
121 FPS 10% low
115 FPS 1% low

Want to compare your GPU against the Radeon RX 6700 XT and these results? Download our free and quick PC Performance Test.

Alternative benchmarks

Here are some benchmark results using alternative testing software

3DMark Graphics

3DMark Graphics

High-end graphics benchmark

12,922
Blender

Blender

Cycles Render (Samples per minute)

1,307
Geekbench 5 (OpenCL)

Geekbench 5 (OpenCL)

OpenCL compute benchmark

102,988
Geekbench 5 (Vulkan)

Geekbench 5 (Vulkan)

Vulkan compute benchmark

70,085
Geekbench 6 (OpenCL)

Geekbench 6 (OpenCL)

OpenCL compute benchmark

96,573
Geekbench 6 (Vulkan)

Geekbench 6 (Vulkan)

Vulkan compute benchmark

115,164

Compare these benchmarks and specs using our GPU Comparison Tool

Specifications

Core Clock 2321 MHz
Boost Clock 2581 MHz
Memory Type GDDR6
Memory Size 12 GiB
Bus Width 192 bit
Memory Bandwidth 375 GB/s
TDP 230 W
Floating Point Performance 13.21 TFLOP/s
Release Date 2021-03-01
Family Radeon RX 6000 Series
PCIe Revision 4
DirectX Support 12
OpenGL Support 4.6
Pixel Rate 165.2 Gigapixels/s
Texture Rate 413 Gigatexels/s
Shading Units 2560
Texture Mapping Units 160
Render Output Processors 64

AMD Radeon RX 6700 XT

The Radeon RX 6700 XT is an AMD GPU that was released in March 2021. This GPU is very good at gaming with a score of 72% in our PC benchmark.

The Radeon RX 6700 XT has 12 GiB of GDDR6 memory, with a total memory bandwidth of 375 GB/s. The memory bus has a width of 192 bits. More memory is beneficial when gaming at high resolutions as the memory needs to store the frame buffer and all the game textures. If you run out of memory, you will experience poor performance as the GPU needs to swap data in and out of the memory as it is used.

In terms of clock speed, the Radeon RX 6700 XT GPU core runs at a frequency of 2321 MHz and if power and temperature permits, it can boost up to 2581 MHz. The core clock is directly related to the performance of a GPU, the higher the clock, the more processing can be done per second. A higher clock does not guarantee better performance by itself, this also depends on the number of shading units and other elements of the pipeline.

As for rendering API support, the Radeon RX 6700 XT supports up to DirectX 12. In addition, in cross-platform titles, OpenGL 4.6 features are supported. Newer APIs are usually more efficient, allowing for better performance in games and better graphical effects.

Power and thermals for the AMD Radeon RX 6700 XT are a TDP (Thermal Design Power) of 230 watts. This measures the amount of heat the GPU produces when running at 100%. This isn't a measure of power consumption, but it's a good estimate.

To figure out your graphics card specs and performance, download our free GPU Benchmark utility.
