AMD Radeon RX 6700 XT

AMD Radeon RX 6700 XT Benchmark

AMD Radeon RX 6700 XT GPU benchmark, specs and release date - 12 GB AMD Radeon RX 6000 Series Graphics card rating. How good is the Radeon RX 6700 XT for gaming?

GPU Benchmark Score

71 %
Very Good score from 23 samples
Low uncertainty
Very Good
21st of 531
13th of 531
23 benchmarks

GPU benchmarks

Here are the performance results of this graphics card in both the hardwareDB Benchmark and other benchmark utilities. Synthetic tests are an estimation of real-world performance using consistent and repeatable benchmarks.

hardwareDB Benchmark

All tests were performed at 1920 x 1080 resolution

Flux Core

Volumetric ray casting test, a computationally expensive method of rendering high-quality scenes

296 FPS average
210 FPS 10% low
200 FPS 1% low


Randomly generated noise sphere test

222 FPS average
217 FPS 10% low
203 FPS 1% low


Procedurally generated city scene with voxel rendering

260 FPS average
216 FPS 10% low
204 FPS 1% low


Real-time noise calculation and ray marching test

126 FPS average
119 FPS 10% low
113 FPS 1% low

Want to compare your GPU against the Radeon RX 6700 XT and these results? Download our free and quick PC Performance Test.

Alternative benchmarks

Here are some benchmark results using alternative testing software

Geekbench (OpenCL)

Geekbench (OpenCL)

OpenCL compute benchmark

Geekbench (Vulkan)

Geekbench (Vulkan)

Vulkan compute benchmark

3DMark Graphics

3DMark Graphics

High-end graphics benchmark


Compare these benchmarks and specs using our GPU Comparison Tool

GPU Comparison

The AMD Radeon RX 6700 XT compared against popular alternatives. Compare against more GPUs with our GPU Comparison Tool.

NVIDIA GeForce RTX 3080
108 %
AMD Radeon RX 6750 XT
75 %
NVIDIA GeForce RTX 3070
72 %
AMD Radeon RX 6700 XT
71 %
NVIDIA GeForce RTX 3060 Ti
65 %
AMD Radeon RX 6600 XT
53 %
NVIDIA GeForce RTX 3060
51 %


Core Clock 2321 MHz
Boost Clock 2581 MHz
Memory Type GDDR6
Memory Size 12 GiB
Bus Width 192 bit
Memory Bandwidth 375 GB/s
TDP 230 W
Floating Point Performance 13.21 TFLOP/s
Release Date 2021-03-01
Family Radeon RX 6000 Series
PCIe Revision 4
DirectX Support 12
OpenGL Support 4.6
Pixel Rate 165.2 Gigapixels/s
Texture Rate 413 Gigatexels/s
Shading Units 2560
Texture Mapping Units 160
Render Output Processors 64

AMD Radeon RX 6700 XT

The Radeon RX 6700 XT is an AMD GPU that was released in March 2021. This GPU is very good at gaming with a score of 71% in our PC benchmark.

The Radeon RX 6700 XT has 12 GiB of GDDR6 memory, with a total memory bandwidth of 375 GB/s. The memory bus has a width of 192 bits. More memory is beneficial when gaming at high resolutions as the memory needs to store the frame buffer and all the game textures. If you run out of memory, you will experience poor performance as the GPU needs to swap data in and out of the memory as it is used.

In terms of clock speed, the Radeon RX 6700 XT GPU core runs at a frequency of 2321 MHz and if power and temperature permits, it can boost up to 2581 MHz. The core clock is directly related to the performance of a GPU, the higher the clock, the more processing can be done per second. A higher clock does not guarantee better performance by itself, this also depends on the number of shading units and other elements of the pipeline.

As for rendering API support, the Radeon RX 6700 XT supports up to DirectX 12. In addition, in cross-platform titles, OpenGL 4.6 features are supported. Newer APIs are usually more efficient, allowing for better performance in games and better graphical effects.

Power and thermals for the AMD Radeon RX 6700 XT are a TDP (Thermal Design Power) of 230 watts. This measures the amount of heat the GPU produces when running at 100%. This isn't a measure of power consumption, but it's a good estimate.

To figure out your graphics card specs and performance, download our free GPU Benchmark utility.
