NVIDIA GeForce RTX 3060 Ti

NVIDIA GeForce RTX 3060 Ti Benchmark

NVIDIA GeForce RTX 3060 Ti GPU benchmark, specs and release date - 8 GB NVIDIA Graphics card rating. How good is the GeForce RTX 3060 Ti for gaming?

GPU Benchmark Score

110 %
Amazing score from 26 samples
Low uncertainty

Ranked 21st out of 536 in the GPU Database. Tests performed at 1920 x 1080 resolution.

Benchmark Average 10% Low 1% Low
Flux Core
Volumetric ray casting test, a computationally expensive method of rendering high-quality scenes
153 FPS 107 FPS 82 FPS
Electron
Randomly generated noise sphere test
79 FPS 72 FPS 52 FPS
City
Procedurally generated city scene with voxel rendering
114 FPS 96 FPS 71 FPS
Clouds
Real-time noise calculation and ray marching test
61 FPS 54 FPS 41 FPS

Want to compare your GPU against the GeForce RTX 3060 Ti and these results? Download our free and quick PC Performance Test.

Geekbench (CUDA)
Geekbench (CUDA)
Geekbench (OpenCL)
Geekbench (OpenCL)
Geekbench (Vulkan)
Geekbench (Vulkan)
3DMark Graphics
3DMark Graphics
128,321 120,183 95,490 11,624

Compare these benchmarks and specs using our GPU Comparison Tool.

GPU Comparison

The NVIDIA GeForce RTX 3060 Ti compared against popular alternatives. Compare against more GPUs with our GPU Comparison Tool.

AMD Radeon RX 6750 XT
128 %
AMD Radeon RX 6700 XT
123 %
NVIDIA GeForce RTX 3070
120 %
NVIDIA GeForce RTX 3060 Ti
110 %
NVIDIA GeForce RTX 2080
96 %
NVIDIA GeForce RTX 3060
80 %
NVIDIA GeForce GTX 1080
80 %

Specifications

Core Clock 1410 MHz
Boost Clock 1665 MHz
Memory Type GDDR6
Memory Size 8 GiB
Bus Width 256 bit
Memory Bandwidth 448 GB/s
TDP 200 W
Floating Point Performance 16.2 TFLOPS
Release Date 2020-12-01
PCIe Revision 4
DirectX Support 12
OpenGL Support 4.6
Pixel Rate 133 Gigapixels/s
Texture Rate 253 Gigatexels/s
Shading Units 4864
Texture Mapping Units 152
Render Output Processors 80

NVIDIA GeForce RTX 3060 Ti

The GeForce RTX 3060 Ti is a GPU from NVIDIA released in 2020. This chip has an amazing gaming score at 110% in our GPU benchmark.

The GeForce RTX 3060 Ti has 8 GiB of GDDR6 memory, with a total memory bandwidth of 437 GB/s. The memory bus has a width of 256 bits. More memory is beneficial when gaming at high resolutions as the memory needs to store the frame buffer and all the game textures. If you run out of memory, you will experience poor performance as the GPU needs to swap data in and out of the memory as it is used.

In terms of clock speed, the GeForce RTX 3060 Ti GPU core runs at a frequency of 1410 MHz and if power and temperature permits, it can boost up to 1665 MHz. The core clock is directly related to the performance of a GPU, the higher the clock, the more processing can be done per second. A higher clock does not guarantee better performance by itself, this also depends on the number of shading units and other elements of the pipeline.

The performance specs of the GeForce RTX 3060 Ti are a raw floating-point performance of 16.2 TFLOPS : this represents the number of floating point (decimal) operations completed per second. In addition, this NVIDIA GPU has a pixel rate of 133 Gigapixels/s, the number of pixels the GPU is capable of outputting every second. Furthermore, it has a texture fill rate of 253 Gigatexels/s, the number of pixels the GPU can renderer per second.

As for rendering API support, the GeForce RTX 3060 Ti supports up to DirectX 12. In addition, in cross-platform titles, OpenGL 4.6 features are supported. Newer APIs are usually more efficient, allowing for better performance in games and better graphical effects.

The raw technical specs of the GeForce RTX 3060 Ti are: 4864 total shading units (general purpose parallel cores capable of processing different aspects of the graphics pipeline), 152 texture mapping units (specialised processors for texture operations, this determines the texture rate) and 80 render output processors or units (the final step in the rendering pipeline, responsible for rasterising the image)

Power and thermals for the NVIDIA GeForce RTX 3060 Ti are a TDP (Thermal Design Power) of 200 watts. This measures the amount of heat the GPU produces when running at 100%. This isn't a measure of power consumption, but it's a good estimate.

To figure out your graphics card specs and performance, download our free GPU Benchmark utility.

Comments

klm

Good performance at 1440p ultra settings in games. Always over 60fps. Great card.

July 09, 2022 Reply
