NVIDIA GeForce RTX 3060 Ti

NVIDIA GeForce RTX 3060 Ti Benchmark and Specs

NVIDIA GeForce RTX 3060 Ti GPU benchmark, specs and release date - 8 GB NVIDIA Graphics card rating. How good is the GeForce RTX 3060 Ti for gaming?

Benchmark Score

66 %
Very Good score from 44 samples
Low uncertainty
Performance
Very Good
Ranking
29th of 363
Popularity
8th of 363
Samples
44 benchmarks

Quick compare

Search for a CPU to compare against or choose a popular comparison below.

GPU Comparison

The NVIDIA GeForce RTX 3060 Ti compared against popular alternatives. Compare against more GPUs with our GPU Comparison Tool.

AMD Radeon RX 6750 XT
76 %
NVIDIA GeForce RTX 3070
74 %
AMD Radeon RX 6700 XT
72 %
NVIDIA GeForce RTX 3060 Ti
66 %
NVIDIA GeForce RTX 2080
64 %
NVIDIA GeForce RTX 3060
51 %
NVIDIA GeForce GTX 1050 Ti
15 %

GPU benchmarks

Here are the performance results of this graphics card in both the hardwareDB Benchmark and other benchmark utilities. Synthetic tests are an estimation of real-world performance using consistent and repeatable benchmarks. All tests were performed at 1920 x 1080 resolution.

Flux Core

Volumetric ray casting test, a computationally expensive method of rendering high-quality scenes

333 FPS average
234 FPS 10% low
195 FPS 1% low

Electron

Randomly generated noise sphere test

165 FPS average
154 FPS 10% low
122 FPS 1% low

City

Procedurally generated city scene with voxel rendering

241 FPS average
205 FPS 10% low
167 FPS 1% low

Clouds

Real-time noise calculation and ray marching test

129 FPS average
118 FPS 10% low
97 FPS 1% low

Want to compare your GPU against the GeForce RTX 3060 Ti and these results? Download our free and quick PC Performance Test.

Alternative benchmarks

Here are some benchmark results using alternative testing software

3DMark Graphics

3DMark Graphics

High-end graphics benchmark

11,624
Blender

Blender

Cycles Render (Samples per minute)

3,065
Geekbench 5 (CUDA)

Geekbench 5 (CUDA)

CUDA compute benchmark

128,321
Geekbench 5 (OpenCL)

Geekbench 5 (OpenCL)

OpenCL compute benchmark

120,183
Geekbench 5 (Vulkan)

Geekbench 5 (Vulkan)

Vulkan compute benchmark

95,490
Geekbench 6 (OpenCL)

Geekbench 6 (OpenCL)

OpenCL compute benchmark

112,103
Geekbench 6 (Vulkan)

Geekbench 6 (Vulkan)

Vulkan compute benchmark

104,641

Compare these benchmarks and specs using our GPU Comparison Tool

Specifications

Core Clock 1410 MHz
Boost Clock 1665 MHz
Memory Type GDDR6
Memory Size 8 GiB
Bus Width 256 bit
Memory Bandwidth 437.5 GB/s
TDP 200 W
Floating Point Performance 16.2 TFLOP/s
Release Date 2020-12-01
PCIe Revision 4
DirectX Support 12
OpenGL Support 4.6
Pixel Rate 133.2 Gigapixels/s
Texture Rate 253.1 Gigatexels/s
Shading Units 4864
Texture Mapping Units 152
Render Output Processors 80

NVIDIA GeForce RTX 3060 Ti

The GeForce RTX 3060 Ti is a GPU from NVIDIA released in 2020. This chip has a very good gaming score at 66% in our GPU benchmark.

The GeForce RTX 3060 Ti has 8 GiB of GDDR6 memory, with a total memory bandwidth of 437 GB/s. The memory bus has a width of 256 bits. When choosing a GPU, plan ahead and select a model with enough memory for your needs. High resolutions such as 4K require significantly more memory than 1080p as there is more data to display on the screen.

In terms of clock speed, the GeForce RTX 3060 Ti GPU core runs at a frequency of 1410 MHz and if power and temperature permits, it can boost up to 1665 MHz. A clock speed is the frequency at which the GPU updates. A higher speed means more processing can happen per cycle. This is useful only when comparing cards of the same generation, as other architectures may process more or less per clock.

As for rendering API support, the GeForce RTX 3060 Ti supports up to DirectX 12. In addition, in cross-platform titles, OpenGL 4.6 features are supported. Newer APIs are usually more efficient, allowing for better performance in games and better graphical effects.

This chip has a Thermal Design Power of 200W: the total amount of waste heat generated. A card that runs hotter will need better cooling and will draw more power from the wall.

To figure out your graphics card specs and performance, download our free GPU Benchmark utility.
