AMD Radeon RX 6750 XT

AMD Radeon RX 6750 XT Benchmark and Specs

AMD Radeon RX 6750 XT GPU benchmark, specs and release date - 12 GB AMD Radeon RX 6000 Series Graphics card rating. How good is the Radeon RX 6750 XT for gaming?

Benchmark Score

76 %
Very Good score from 12 samples
Low uncertainty
Performance
Very Good
Ranking
23rd of 363
Popularity
36th of 363
Samples
12 benchmarks

Gaming benchmarks

Here is the performance of the Radeon RX 6750 XT is some popular titles. The frame rate may depend on the display resolution, the graphics preset and the test system CPU.

Battlefield V

Battlefield V

194 FPS average
160 FPS 1% low
Forza Horizon 4

Forza Horizon 4

132 FPS average
113 FPS 1% low
Grand Theft Auto V

Grand Theft Auto V

143 FPS average
142 FPS 1% low
Metro Exodus

Metro Exodus

102 FPS average
95 FPS 1% low
The Witcher 3

The Witcher 3

159 FPS average
130 FPS 1% low
Shadow of the Tomb Raider

Shadow of the Tomb Raider

138 FPS average
92 FPS 1% low

Quick compare

Search for a CPU to compare against or choose a popular comparison below.

GPU Comparison

The AMD Radeon RX 6750 XT compared against popular alternatives. Compare against more GPUs with our GPU Comparison Tool.

AMD Radeon RX 6800 XT
116 %
NVIDIA GeForce RTX 3070 Ti
88 %
AMD Radeon RX 6750 XT
76 %
NVIDIA GeForce RTX 3070
74 %
AMD Radeon RX 6700 XT
72 %
NVIDIA GeForce RTX 3060 Ti
66 %
NVIDIA GeForce GTX 1080 Ti
62 %

GPU benchmarks

Here are the performance results of this graphics card in both the hardwareDB Benchmark and other benchmark utilities. Synthetic tests are an estimation of real-world performance using consistent and repeatable benchmarks. All tests were performed at 1920 x 1080 resolution.

Flux Core

Volumetric ray casting test, a computationally expensive method of rendering high-quality scenes

313 FPS average
229 FPS 10% low
217 FPS 1% low

Electron

Randomly generated noise sphere test

236 FPS average
231 FPS 10% low
214 FPS 1% low

City

Procedurally generated city scene with voxel rendering

278 FPS average
229 FPS 10% low
216 FPS 1% low

Clouds

Real-time noise calculation and ray marching test

135 FPS average
128 FPS 10% low
117 FPS 1% low

Want to compare your GPU against the Radeon RX 6750 XT and these results? Download our free and quick PC Performance Test.

Alternative benchmarks

Here are some benchmark results using alternative testing software

3DMark Graphics

3DMark Graphics

High-end graphics benchmark

13,565
Blender

Blender

Cycles Render (Samples per minute)

1,349
Geekbench 6 (OpenCL)

Geekbench 6 (OpenCL)

OpenCL compute benchmark

104,655
Geekbench 6 (Vulkan)

Geekbench 6 (Vulkan)

Vulkan compute benchmark

111,989

Compare these benchmarks and specs using our GPU Comparison Tool

Specifications

Core Clock 2150 MHz
Boost Clock 2600 MHz
Memory Type GDDR6
Memory Size 12 GiB
Bus Width 192 bit
Memory Bandwidth 421.88 GB/s
TDP 250 W
Floating Point Performance 13.31 TFLOP/s
Release Date 2022-05-10
Family Radeon RX 6000 Series
PCIe Revision 4
DirectX Support 12
OpenGL Support 4.6
Pixel Rate 166.4 Gigapixels/s
Texture Rate 416 Gigatexels/s
Shading Units 2560
Texture Mapping Units 160
Render Output Processors 64

AMD Radeon RX 6750 XT

The Radeon RX 6750 XT is an AMD GPU that was released in May 2022. This GPU is very good at gaming with a score of 76% in our PC benchmark.

The Radeon RX 6750 XT has 12 GiB of GDDR6 memory, with a total memory bandwidth of 421 GB/s. The memory bus has a width of 192 bits. When choosing a GPU, plan ahead and select a model with enough memory for your needs. High resolutions such as 4K require significantly more memory than 1080p as there is more data to display on the screen.

In terms of clock speed, the Radeon RX 6750 XT GPU core runs at a frequency of 2150 MHz and if power and temperature permits, it can boost up to 2600 MHz. A clock speed is the frequency at which the GPU updates. A higher speed means more processing can happen per cycle. This is useful only when comparing cards of the same generation, as other architectures may process more or less per clock.

As for rendering API support, the Radeon RX 6750 XT supports up to DirectX 12. In addition, in cross-platform titles, OpenGL 4.6 features are supported. Newer APIs are usually more efficient, allowing for better performance in games and better graphical effects.

This chip has a Thermal Design Power of 250W: the total amount of waste heat generated. A card that runs hotter will need better cooling and will draw more power from the wall.

To figure out your graphics card specs and performance, download our free GPU Benchmark utility.
