AMD Radeon RX 6750 XT

AMD Radeon RX 6750 XT Benchmark

AMD Radeon RX 6750 XT GPU benchmark, specs and release date - 12 GB AMD Radeon RX 6000 Series Graphics card rating. How good is the Radeon RX 6750 XT for gaming?

GPU Benchmark Score

127 %
Incredible score from 8 samples
Low uncertainty

Ranked 12th out of 526 in the GPU Database. Tests performed at 1920 x 1080 resolution.

Benchmark Average 10% Low 1% Low
Flux Core
Volumetric ray casting test, a computationally expensive method of rendering high-quality scenes
139 FPS 105 FPS 101 FPS
Electron
Randomly generated noise sphere test
113 FPS 110 FPS 102 FPS
City
Procedurally generated city scene with voxel rendering
126 FPS 105 FPS 100 FPS
Clouds
Real-time noise calculation and ray marching test
64 FPS 60 FPS 56 FPS

Want to compare your GPU against the Radeon RX 6750 XT and these results? Download our free and quick PC Performance Test.

Compare these benchmarks and specs using our GPU Comparison Tool.

GPU Comparison

The AMD Radeon RX 6750 XT compared against popular alternatives. Compare against more GPUs with our GPU Comparison Tool.

AMD Radeon RX 6800 XT
180 %
NVIDIA GeForce RTX 3070 Ti
140 %
AMD Radeon RX 6750 XT
127 %
AMD Radeon RX 6700 XT
121 %
NVIDIA GeForce RTX 3070
116 %
NVIDIA GeForce RTX 3060 Ti
107 %
NVIDIA GeForce GTX 1080 Ti
104 %

Specifications

Core Clock 2150 MHz
Boost Clock 2600 MHz
Memory Type GDDR6
Memory Size 12 GiB
Bus Width 192 bit
Memory Bandwidth 432 GB/s
TDP 250 W
Floating Point Performance 13.31 TFLOPS
Release Date 2022-05-10
Family Radeon RX 6000 Series
PCIe Revision 4
DirectX Support 12
OpenGL Support 4.6
Pixel Rate 166 Gigapixels/s
Texture Rate 416 Gigatexels/s
Shading Units 2560
Texture Mapping Units 160
Render Output Processors 64

AMD Radeon RX 6750 XT

The Radeon RX 6750 XT is a GPU from AMD released in 2022. This chip has an incredible gaming score at 127% in our GPU benchmark.

The Radeon RX 6750 XT has 12 GiB of GDDR6 memory, with a total memory bandwidth of 421 GB/s. The memory bus has a width of 192 bits. More memory is beneficial when gaming at high resolutions as the memory needs to store the frame buffer and all the game textures. If you run out of memory, you will experience poor performance as the GPU needs to swap data in and out of the memory as it is used.

In terms of clock speed, the Radeon RX 6750 XT GPU core runs at a frequency of 2150 MHz and if power and temperature permits, it can boost up to 2600 MHz. The core clock is directly related to the performance of a GPU, the higher the clock, the more processing can be done per second. A higher clock does not guarantee better performance by itself, this also depends on the number of shading units and other elements of the pipeline.

The performance specs of the Radeon RX 6750 XT are a raw floating-point performance of 13.31 TFLOPS : this represents the number of floating point (decimal) operations completed per second. In addition, this AMD GPU has a pixel rate of 166 Gigapixels/s, the number of pixels the GPU is capable of outputting every second. Furthermore, it has a texture fill rate of 416 Gigatexels/s, the number of pixels the GPU can renderer per second.

As for rendering API support, the Radeon RX 6750 XT supports up to DirectX 12. In addition, in cross-platform titles, OpenGL 4.6 features are supported. Newer APIs are usually more efficient, allowing for better performance in games and better graphical effects.

The raw technical specs of the Radeon RX 6750 XT are: 2560 total shading units (general purpose parallel cores capable of processing different aspects of the graphics pipeline), 160 texture mapping units (specialised processors for texture operations, this determines the texture rate) and 64 render output processors or units (the final step in the rendering pipeline, responsible for rasterising the image)

Power and thermals for the AMD Radeon RX 6750 XT are a TDP (Thermal Design Power) of 250 watts. This measures the amount of heat the GPU produces when running at 100%. This isn't a measure of power consumption, but it's a good estimate.

To figure out your graphics card specs and performance, download our free GPU Benchmark utility.
