AMD Radeon R5

AMD Radeon R5 Benchmark

AMD Radeon R5 GPU benchmark, specs and release date - AMD Graphics card rating. How good is the Radeon R5 for gaming?

GPU Benchmark Score

2 %
Bad score from 5 samples
Medium uncertainty

Ranked 431st out of 526 in the GPU Database. Tests performed at 1920 x 1080 resolution.

Benchmark Average 10% Low 1% Low
Flux Core
Volumetric ray casting test, a computationally expensive method of rendering high-quality scenes
3 FPS 2 FPS 2 FPS
Electron
Randomly generated noise sphere test
2 FPS 2 FPS 3 FPS
City
Procedurally generated city scene with voxel rendering
2 FPS 2 FPS 1 FPS
Clouds
Real-time noise calculation and ray marching test
1 FPS 0 FPS 2 FPS

Want to compare your GPU against the Radeon R5 and these results? Download our free and quick PC Performance Test.

Geekbench (OpenCL)
Geekbench (OpenCL)
Geekbench (Vulkan)
Geekbench (Vulkan)
4,869 5,160

Compare these benchmarks and specs using our GPU Comparison Tool.

GPU Comparison

The AMD Radeon R5 compared against popular alternatives. Compare against more GPUs with our GPU Comparison Tool.

NVIDIA GeForce GT 1030
12 %
AMD Radeon Vega 8
8 %
NVIDIA GeForce GT 730
4 %
Intel Iris 5100
3 %
AMD Radeon R5
2 %
AMD Radeon HD 8500M
2 %
NVIDIA GeForce GT 630
2 %

Specifications

Core Clock 200 MHz
Boost Clock 900 MHz
TDP 15 W
Release Date 2017-09-05
DirectX Support 12
OpenGL Support 4.6
Pixel Rate 3 Gigapixels/s
Texture Rate 12 Gigatexels/s
Shading Units 256
Texture Mapping Units 16
Render Output Processors 4

AMD Radeon R5

The Radeon R5 is a GPU from AMD released in 2017. This chip has a bad gaming score at 2% in our GPU benchmark.

In terms of clock speed, the Radeon R5 GPU core runs at a frequency of 200 MHz and if power and temperature permits, it can boost up to 900 MHz. The core clock is directly related to the performance of a GPU, the higher the clock, the more processing can be done per second. A higher clock does not guarantee better performance by itself, this also depends on the number of shading units and other elements of the pipeline.

The performance specs of the Radeon R5 are this AMD GPU has a pixel rate of 3 Gigapixels/s, the number of pixels the GPU is capable of outputting every second. Furthermore, it has a texture fill rate of 12 Gigatexels/s, the number of pixels the GPU can renderer per second.

As for rendering API support, the Radeon R5 supports up to DirectX 12. In addition, in cross-platform titles, OpenGL 4.6 features are supported. Newer APIs are usually more efficient, allowing for better performance in games and better graphical effects.

The raw technical specs of the Radeon R5 are: 256 total shading units (general purpose parallel cores capable of processing different aspects of the graphics pipeline), 16 texture mapping units (specialised processors for texture operations, this determines the texture rate) and 4 render output processors or units (the final step in the rendering pipeline, responsible for rasterising the image)

Power and thermals for the AMD Radeon R5 are a TDP (Thermal Design Power) of 15 watts. This measures the amount of heat the GPU produces when running at 100%. This isn't a measure of power consumption, but it's a good estimate.

To figure out your graphics card specs and performance, download our free GPU Benchmark utility.
