NVIDIA GeForce RTX 2060

NVIDIA GeForce RTX 2060 Benchmark

NVIDIA GeForce RTX 2060 GPU benchmark, specs and release date - 6 GB NVIDIA Graphics card rating. How good is the GeForce RTX 2060 for gaming?

GPU Benchmark Score

76 %
Very Good score from 58 samples
Low uncertainty

Ranked 44th out of 536 in the GPU Database. Tests performed at 1920 x 1080 resolution.

Benchmark Average 10% Low 1% Low
Flux Core
Volumetric ray casting test, a computationally expensive method of rendering high-quality scenes
97 FPS 71 FPS 52 FPS
Electron
Randomly generated noise sphere test
65 FPS 60 FPS 44 FPS
City
Procedurally generated city scene with voxel rendering
69 FPS 54 FPS 44 FPS
Clouds
Real-time noise calculation and ray marching test
48 FPS 43 FPS 34 FPS

Want to compare your GPU against the GeForce RTX 2060 and these results? Download our free and quick PC Performance Test.

Geekbench (CUDA)
Geekbench (CUDA)
Geekbench (OpenCL)
Geekbench (OpenCL)
Geekbench (Vulkan)
Geekbench (Vulkan)
3DMark Graphics
3DMark Graphics
78,091 70,754 60,775 7,504

Compare these benchmarks and specs using our GPU Comparison Tool.

GPU Comparison

The NVIDIA GeForce RTX 2060 compared against popular alternatives. Compare against more GPUs with our GPU Comparison Tool.

AMD Radeon RX 6600 XT
93 %
NVIDIA GeForce RTX 3060
80 %
NVIDIA GeForce RTX 2060
76 %
NVIDIA GeForce GTX 1660 SUPER
60 %
NVIDIA GeForce RTX 3050
59 %
AMD Radeon RX 6500 XT
52 %
NVIDIA GeForce GTX 1650
37 %

Specifications

Core Clock 1365 MHz
Boost Clock 1680 MHz
Memory Type GDDR6
Memory Size 6 GiB
Bus Width 192 bit
Memory Bandwidth 336 GB/s
TDP 160 W
Floating Point Performance 6.45 TFLOPS
Release Date 2019-01-07
PCIe Revision 3.00
DirectX Support 12.00
OpenGL Support 4.60
Pixel Rate 81 Gigapixels/s
Texture Rate 202 Gigatexels/s
Shading Units 1920
Texture Mapping Units 120
Render Output Processors 48

NVIDIA GeForce RTX 2060

The GeForce RTX 2060 is a GPU from NVIDIA released in 2019. This chip has a very good gaming score at 76% in our GPU benchmark.

The GeForce RTX 2060 has 6 GiB of GDDR6 memory, with a total memory bandwidth of 328 GB/s. The memory bus has a width of 192 bits. More memory is beneficial when gaming at high resolutions as the memory needs to store the frame buffer and all the game textures. If you run out of memory, you will experience poor performance as the GPU needs to swap data in and out of the memory as it is used.

In terms of clock speed, the GeForce RTX 2060 GPU core runs at a frequency of 1365 MHz and if power and temperature permits, it can boost up to 1680 MHz. The core clock is directly related to the performance of a GPU, the higher the clock, the more processing can be done per second. A higher clock does not guarantee better performance by itself, this also depends on the number of shading units and other elements of the pipeline.

The performance specs of the GeForce RTX 2060 are a raw floating-point performance of 6.45 TFLOPS : this represents the number of floating point (decimal) operations completed per second. In addition, this NVIDIA GPU has a pixel rate of 81 Gigapixels/s, the number of pixels the GPU is capable of outputting every second. Furthermore, it has a texture fill rate of 202 Gigatexels/s, the number of pixels the GPU can renderer per second.

As for rendering API support, the GeForce RTX 2060 supports up to DirectX 12.00. In addition, in cross-platform titles, OpenGL 4.60 features are supported. Newer APIs are usually more efficient, allowing for better performance in games and better graphical effects.

The raw technical specs of the GeForce RTX 2060 are: 1920 total shading units (general purpose parallel cores capable of processing different aspects of the graphics pipeline), 120 texture mapping units (specialised processors for texture operations, this determines the texture rate) and 48 render output processors or units (the final step in the rendering pipeline, responsible for rasterising the image)

Power and thermals for the NVIDIA GeForce RTX 2060 are a TDP (Thermal Design Power) of 160 watts. This measures the amount of heat the GPU produces when running at 100%. This isn't a measure of power consumption, but it's a good estimate.

To figure out your graphics card specs and performance, download our free GPU Benchmark utility.
