NVIDIA GeForce GTX 1630

NVIDIA GeForce GTX 1630 Benchmark and Specs

NVIDIA GeForce GTX 1630 GPU benchmark, specs and release date - NVIDIA Graphics card rating. How good is the GeForce GTX 1630 for gaming?

Benchmark Score

1,317
Average score from 1 sample
High uncertainty
Performance
Average
Ranking
242nd of 586
Popularity
313th of 586
Samples
1 benchmarks

Gaming benchmarks

Here is the performance of the GeForce GTX 1630 is some popular titles. The frame rate may depend on the display resolution, the graphics preset and the test system CPU.

Apex Legends

Apex Legends

91 FPS average
55 FPS 1% low
God of War

God of War

37 FPS average
34 FPS 1% low
Valorant

Valorant

204 FPS average
70 FPS 1% low
Grand Theft Auto V

Grand Theft Auto V

63 FPS average
61 FPS 1% low
Forza Horizon 5

Forza Horizon 5

43 FPS average
26 FPS 1% low
Far Cry 6

Far Cry 6

44 FPS average
39 FPS 1% low
Cyberpunk 2077

Cyberpunk 2077

40 FPS average
37 FPS 1% low
Red Dead Redemption 2

Red Dead Redemption 2

45 FPS average
39 FPS 1% low
ELDEN RING

ELDEN RING

47 FPS average
43 FPS 1% low

Quick compare

Search for a CPU to compare against or choose a popular comparison below.

GeForce GTX 1050 Ti
vs. GeForce GTX 1050 Ti
GeForce GTX 1650
vs. GeForce GTX 1650
Radeon RX 580
vs. Radeon RX 580
GeForce GTX 770
vs. GeForce GTX 770
Radeon RX 470
vs. Radeon RX 470
GeForce GTX 970
vs. GeForce GTX 970
Radeon RX 6400
vs. Radeon RX 6400
Radeon RX 560
vs. Radeon RX 560
GeForce GTX 1650 SUPER
vs. GeForce GTX 1650 SUPER
Radeon 780M
vs. Radeon 780M
Radeon TM
vs. Radeon TM
GeForce RTX 3050
vs. GeForce RTX 3050

GPU Comparison

The NVIDIA GeForce GTX 1630 compared against popular alternatives. Compare against more GPUs with our GPU Comparison Tool.

AMD Radeon RX 580
2,281 points
NVIDIA GeForce GTX 970
2,262 points
NVIDIA GeForce GTX 1650
2,244 points
AMD Radeon RX 470
1,827 points
NVIDIA GeForce GTX 1050 Ti
1,456 points
NVIDIA GeForce GTX 770
1,335 points
NVIDIA GeForce GTX 1630
1,317 points

GPU benchmarks

Here are the performance results of this graphics card in both the hardwareDB Benchmark and other benchmark utilities. Synthetic tests are an estimation of real-world performance using consistent and repeatable benchmarks. All tests were performed at 1920 x 1080 resolution.

Flux Core

Volumetric ray casting test, a computationally expensive method of rendering high-quality scenes

52 FPS average
43 FPS 10% low
36 FPS 1% low

Electron

Randomly generated noise sphere test

37 FPS average
36 FPS 10% low
34 FPS 1% low

City

Procedurally generated city scene with voxel rendering

43 FPS average
37 FPS 10% low
35 FPS 1% low

Clouds

Real-time noise calculation and ray marching test

28 FPS average
26 FPS 10% low
19 FPS 1% low

Want to compare your GPU against the GeForce GTX 1630 and these results? Download our free and quick PC Performance Test.

Download GPU Benchmark

Alternative benchmarks

Here are some benchmark results using alternative testing software

Blender

Blender

Cycles Render (Samples per minute)

265
Geekbench 6 (OpenCL)

Geekbench 6 (OpenCL)

OpenCL compute benchmark

24,898
Geekbench 6 (Vulkan)

Geekbench 6 (Vulkan)

Vulkan compute benchmark

23,619

Compare these benchmarks and specs using our GPU Comparison Tool

Specifications

Core Clock 1740 MHz
Boost Clock 1785 MHz
Memory Type GDDR6
Bus Width 64 bit
Memory Bandwidth 96 GB/s
TDP 75 W
Floating Point Performance 1.83 TFLOP/s
Release Date 2022-06-28
PCIe Revision 3.0
DirectX Support 12
OpenGL Support 4.6
Pixel Rate 28.56 Gigapixels/s
Texture Rate 57.12 Gigatexels/s
Shading Units 512
Texture Mapping Units 32
Render Output Processors 16

NVIDIA GeForce GTX 1630

Released in 2022, the GeForce GTX 1630 is a GPU from NVIDIA. According to our GPU Benchmark, this GPU is an average card for gaming with a score of 1317 points.

It has a total memory bandwidth of 93 GB/s. The memory bus has a width of 64 bits.

In terms of clock speed, the GeForce GTX 1630 GPU core runs at a frequency of 1740 MHz and if power and temperature permits, it can boost up to 1785 MHz. The core clock is directly related to the performance of a GPU, the higher the clock, the more processing can be done per second. A higher clock does not guarantee better performance by itself, this also depends on the number of shading units and other elements of the pipeline.

As for rendering API support, the GeForce GTX 1630 supports up to DirectX 12. In addition, in cross-platform titles, OpenGL 4.6 features are supported. Newer APIs are usually more efficient, allowing for better performance in games and better graphical effects.

The NVIDIA GeForce GTX 1630 has a TDP of 75W, this is the amount of heat energy produced by the chip as a byproduct. The higher the TDP, the more heat is produced.

To figure out your graphics card specs and performance, download our free GPU Benchmark utility.
