NVIDIA GeForce GTX 1070 Benchmark

NVIDIA GeForce GTX 1070

The GeForce GTX 1070 is a GPU from NVIDIA released in 2016. This chip has a very good gaming score at 62% in our GPU benchmark.

The GeForce GTX 1070 has 8 GiB of GDDR5 memory, with a total memory bandwidth of 250 GB/s. The memory bus has a width of 256 bits. More memory is beneficial when gaming at high resolutions as the memory needs to store the frame buffer and all the game textures. If you run out of memory, you will experience poor performance as the GPU needs to swap data in and out of the memory as it is used.

In terms of clock speed, the GeForce GTX 1070 GPU core runs at a frequency of 1506 MHz and if power and temperature permits, it can boost up to 1683 MHz. The core clock is directly related to the performance of a GPU, the higher the clock, the more processing can be done per second. A higher clock does not guarantee better performance by itself, this also depends on the number of shading units and other elements of the pipeline.

The performance specs of the GeForce GTX 1070 are a raw floating-point performance of 6.46 TFLOPS : this represents the number of floating point (decimal) operations completed per second. In addition, this NVIDIA GPU has a pixel rate of 108 Gigapixels/s, the number of pixels the GPU is capable of outputting every second. Furthermore, it has a texture fill rate of 202 Gigatexels/s, the number of pixels the GPU can renderer per second.

As for rendering API support, the GeForce GTX 1070 supports up to DirectX 12. In addition, in cross-platform titles, OpenGL 4.5 features are supported. Newer APIs are usually more efficient, allowing for better performance in games and better graphical effects.

The raw technical specs of the GeForce GTX 1070 are: 1920 total shading units (general purpose parallel cores capable of processing different aspects of the graphics pipeline), 120 texture mapping units (specialised processors for texture operations, this determines the texture rate) and 64 render output processors or units (the final step in the rendering pipeline, responsible for rasterising the image)

Power and thermals for the NVIDIA GeForce GTX 1070 are a TDP (Thermal Design Power) of 150 watts. This measures the amount of heat the GPU produces when running at 100%. This isn't a measure of power consumption, but it's a good estimate.

To figure out your graphics card specs and performance, download our free GPU Benchmark utility.
